LUCAS Nano 300 is the product of the HK Audio engineering division’s considerable R&D capabilities. All that collective know-how culminated in the smallest, most efficient and most versatile LUCAS yet.

In fact, LUCAS Nano 300 is probably the world’s smallest, lightest, and pound-for-pound loudest PA! It can be a fullrange rig for pub gigs, a keyboards and e-drums monitor, or a compact PA for DJs. But whatever the scenario, LUCAS Nano 300 always delivers clear, assertive sound, leaves a tiny footprint, and handles with utmost ease, including the onboard mixing console.

Lucas Nano 300

Different configurations for different scenario

LUCAS NANO Twin-Satellite

The Easy-Click connector links two LUCAS NANO 300 satellites to create a single powerful mono satellite. A built-in filter circuit is activated automatically. It voices the two satellites to blend as one, conjuring the acoustics and response of a single cabinet.

Technical Specifications

Model Satellite Double
Max SPL peak 120 dB
Mid/high unit dispersion pattern, horizontal/vertical     60° x 40°
Output power system 70 W @ 4 Ohm
Frequency response 190 Hz – 20 kHz
Maximum SPL, @ 10% THD 116 dB
Dimensions (WxHxD) 13 x 26 x 11,5 cm
Weight 2 kg
Model Subwoofer
Max SPL peak                                                              118 dB
Output power system 160 W @ 2 Ohm
Frequency response 44 Hz – fx
Maximum SPL, @ 10% THD 116 dB
Dimensions (WxHxD) 30 x 39 x 42 cm
Weight 8.3 kg
Model Satellite Single
Max SPL peak 116 dB
Mid/high unit dispersion pattern, horizontal/vertical     60° x 40°
Output power system 35 W @ 8 Ohm
Frequency response 190 Hz – 20 kHz
Maximum SPL, @ 10% THD 112 dB
Dimensions (WxHxD) 13 x 13 x 11,5 cm
Weight 1 kg

Applications

Accoustic Guitar

Presentation

Home Cinema

Desktop Recording/Gaming

Drum

Party

Keyboard
